DC Power Supply

Publication time : 2018-6-14 14:08:41
DC Power Supply
It provides the stable DC voltage and DC current, has the function to keep constant voltage, current and power, adopts the IGBT as main control element and is characterized by small volume, high efficiency, high precision and fast dynamic response.

  The monitoring and communication chip adopts ARM32 bit processor, which can be applied to various intelligent control schemes.

  The IGBT is the main control element, and the medium and high frequency transformers are isolated.

  Automatic switching of constant voltage, constant current and constant power.

  The dynamic response and the speed of stability are fast.

  High precision and small output ripple.

  The external battery pack is equipped with charge and discharge management function.

  The protection function is complete, overload, overpressure, overcurrent, over temperature, under voltage, short circuit and so on.

  LCD parameter display, setting value and actual value are displayed at the same time.

  RS232 communication interface, standard MODBUS-RTU protocol, can be transferred to any other protocol.

Input parameters

Name

Idex

Remarks

Rated voltage

3 phase 380V/400V(any voltage can be customized)
1 phase 220V/230V(any voltage can be customized)

3 phase 3wires(L1,L2,L3)+ PE

1 phase 2 wires (L,N)+ PE

Input voltage range

±10%(other range can be customized)



Input frequency

40-70HZ



12 pulse rectifier transformer

Phase-shifting transformer

option, non - standard

Efficency

>92%

different load rates may be biased

Power factor

>0.95




Output parameters

Name

Idex

Remarks

Output DC voltage

5-20000V



Out put DC current

5-50000A



Stabilized voltage precision

≤0.5%



Stabilized current precision

≤0.5%



Ripple voltage

≤1%(Vrms)




Control parameters

Name

Idex

Remarks

Main control element

ARM32 bit processor is used in the main measurement control chip



Control frequency

10-100KHZ

Determined according to the power and heat dissipation

Control voltage and current acquisition mode

Acquisition of DC voltage and current isolation sensor



Control mode

Voltage closed loop control mode, current closed loop mode, voltage current double feedback closed loop mode.



Interface

RS232,MODBUS-RTU协议

RS485,TCP/IP,GPRS are selectable


Display parameters

Name

Idex

Remarks

Display medium

128*32(LCD)or 7 inch touch screen



Display rated parameters

output DC voltage, current, power and load percentage; set value voltage, current and power.



Display alarm content

Voltage fault feedback , current fault feedback , IGBT alarm, inversion alarm, output overload, high temperature.



Rated parameter display precision

1.0 grade



Voltage parameter resolution

0.1V or 0.01V

Customizable higher resolution

Current parameter resolution

0.1A or 0.01A

Customizable higher resolution


Protection parameters

Name

Idex

Remarks

Protective species

Voltage fault feedback , current fault feedback , IGBT alarm, inversion alarm, output overload, high temperature.



Protection method

1. Cut off the output ;
2, limiting current and pressure.




Physical parameters

Name

Idex

Remarks

Cooling Mode

Natural cooling or forced air cooling or water cooling



Protection degree

Indoor IP21; outdoor IP33 or higher level

Name composition




Model

DPH-10/200

DPH-10/300

DPH-10/400

DPH-10/600

DPH-10/800

DPH-10/1000

DPH-10/1200

DPH-10/1500

DPH-10/2000

DPH-10/3000

DPH-10/6000

DPH-10/10000

DPH-20/200

DPH-20/300

DPH-20/400

DPH-20/600

DPH-20/800

DPH-20/1000

DPH-20/1200

DPH-20/1500

DPH-20/2000

DPH-20/3000

DPH-20/6000

DPH-20/10000

DPH-30/200

DPH-30/300

DPH-30/400

DPH-30/600

DPH-30/800

DPH-30/1000

DPH-30/1200

DPH-30/1500

DPH-30/2000

DPH-30/3000

DPH-30/6000

DPH-30/10000

DPH-50/200

DPH-50/300

DPH-50/400

DPH-50/600

DPH-50/800

DPH-50/1000

DPH-50/1200

DPH-50/1500

DPH-50/2000

DPH-50/3000

DPH-50/6000

DPH-50/10000

DPH-80/50

DPH-80/100

DPH-80/150

DPH-80/200

DPH-80/300

DPH-80/400

DPH-80/600

DPH-80/800

DPH-80/1000

DPH-80/1200

DPH-80/1500

DPH-80/2000

DPH-120/10

DPH-120/20

DPH-120/30

DPH-120/50

DPH-120/100

DPH-120/150

DPH-120/200

DPH-120/300

DPH-120/400

DPH-120/600

DPH-120/800

DPH-120/1000

DPH-180/10

DPH-180/20

DPH-180/30

DPH-180/50

DPH-180/100

DPH-180/150

DPH-180/200

DPH-180/300

DPH-180/400

DPH-180/600

DPH-180/800

DPH-180/1000

DPH-250/10

DPH-250/20

DPH-250/30

DPH-250/50

DPH-250/100

DPH-250/150

DPH-250/200

DPH-250/300

DPH-250/400

DPH-250/600

DPH-250/800

DPH-250/1000

DPH-300/10

DPH-300/20

DPH-300/30

DPH-300/50

DPH-300/100

DPH-300/150

DPH-300/200

DPH-300/300

DPH-300/400

DPH-300/600

DPH-300/800

DPH-300/1000

DPH-400/10

DPH-400/20

DPH-400/30

DPH-400/50

DPH-400/100

DPH-400/150

DPH-400/200

DPH-400/300

DPH-400/400

DPH-400/600

DPH-400/800

DPH-400/1000

DPH-600/10

DPH-600/20

DPH-600/30

DPH-600/50

DPH-600/100

DPH-600/150

DPH-600/200

DPH-600/300

DPH-600/400

DPH-600/600

DPH-600/800

DPH-600/1000

DPH-800/5

DPH-800/10

DPH-800/20

DPH-800/30

DPH-800/50

DPH-800/100

DPH-800/200

DPH-800/300

DPH-800/400

DPH-1000/5

DPH-1000/10

DPH-1000/20

DPH-1000/30

DPH-1000/50

DPH-1000/100

DPH-1000/200

DPH-1000/300

DPH-1000/400

Communication room, power control, charging pile, charging, sewage treatment, electrolytic plating, induction heating...
